  TAL-US 系列歐化三相分離式真空填料機是在原有三相分離式填料機基礎上，開發設計的一款功能強大、外表美觀、安裝操作簡便的填料機。各機型采用不銹鋼料門，確保原料不受污染 ; 采用高壓風機為動力核心，具有不易損壞，吸力大，使用壽命長等
特點。另提供經濟型機種供客戶選擇。TAL-US 系列真空粉體填料機，它具備 TAL-US 系列產品的一切特點，同時，另有雙段風機
可供選配 ; 根據其在用戶端的不同使用情形，可選擇裝載不同過濾器的料桶 , 適用于含粉量 30% 及 100% 的輸送作業。
TAL-US | 系列
The TAL-US series Europeanized three-phase separation vacuum packing machine is a powerful, aesthetically pleasing, and easy to
install and operate packing machine developed and designed on the basis of the original three-phase separation packing machine. Each
model adopts stainless steel material doors to ensure that raw materials are not contaminated; Using high-pressure fans as the power
core, it has the characteristics of being not easily damaged, having high suction force, and long service life. We also provide economical
models for customers to choose from. The TAL-US series vacuum powder filler machine has all the characteristics of the TAL-US series
products, and there is also a dual stage fan available for optional configuration; According to its different usage on the user end, different
filter buckets can be selected for loading, suitable for conveying operations with powder content of 30% and 100%.  微處理器配記憶本使用 EEPROM, 不會丟失設定資料可永久保存； 下吸風式設計 , 濾清器下搭配旋風擋板與分離式的集塵桶 , 有效地減輕濾清器的負荷 ; 可直接配置歐化兩料比例 閥閥體使用 ;
料斗可選配自動清洗裝置 , 附布質濾網 , 機型后加注“C”,TAL-12U-C/CE 以上機型可額外選配儲壓罐，機型后面加注“A”;
可依客戶需求提供經濟型系列 , 降低成本 ( 經濟型機配置布質濾網 , 并取消二度過濾網 );
提供多功能安裝架 HMB-900 供選配******調整直徑為 900mm;
提供標準型和保溫型歐化集料斗 TAL-6U/12U/24U 供選配 (TAL-UGP 系列除外 );
TAL-UG 系列共有兩種過濾器裝置，布袋式與板式，適用于 30% 及 100% 含粉量的輸送作業 , 可根據客戶需求做搭配 , 儲壓罐 , 自動噴洗裝置為標準配置 ;
TAL-1HP/2HP-UG 可選配旋風集塵器 ;
TAL-UGP 系列主機配備單、雙段風機 (3.5HP 以上 ) 可供客戶之需求 ;
TAL-UG 系列當輸送的原料當中 , 粉碎料占 30% 以上時，可選配 14 目的不銹鋼濾網 ;
改為歐規安全回路機型時，機型后加注“CE”。
The microprocessor with memory book uses EEPROM, which will not lose setting data and can be permanently saved;
The downward suction design is equipped with a cyclone baffle and a separate dust collection bucket under the filter, effectively reducing the load on the filter; Can be directly configured
with a Europeanized two material proportional valve body for use;
The hopper can be equipped with an automatic cleaning device and a fabric filter. The model can be filled with "C", and models above TAL-12U-C/CE can be additionally equipped with a
pressure storage tank. The model can be filled with "A" at the back;
We can provide economy series according to customer needs to reduce costs (economy machines are equipped with fabric filters and secondary filters are eliminated);
Provide multifunctional mounting bracket HMB-900 for optional maximum adjustment diameter of 900mm;
Provide standard and insulated Europeanized aggregate hoppers TAL-6U/12U/24U for optional configuration (excluding the TAL-UGP series);
The TAL-UG series has two types of filter devices, bag type and plate type, suitable for conveying operations with 30% and 100% powder content. They can be matched according to
customer needs. The pressure storage tank and automatic spray washing device are standard configurations;
TAL-1HP/2HP-UG can be optionally equipped with a cyclone dust collector;
The TAL-UGP series host is equipped with single and double stage fans (above 3.5HP) to meet the needs of customers;
When more than 30% of the raw materials conveyed by the TAL-UG series are crushed materials, a 14 mesh stainless steel filter can be optionally equipped;
When changing to a European safety circuit model, add "CE" after the model  |
|
