TCM 系列計量式色母混合機適用于新料、次料、色母或添加劑等的自動比例混合。該系列機型使用直流無刷式馬達 , 依據預選設定的比例混合 , 透過觸控屏微電腦控制系統設定的條件自動轉換成轉速直接驅動精密螺桿擠出原料 , 其誤差值不高于±1%。該產品的馬達減速比分為 30:1 及 100:1 兩種 , 螺桿直徑區分為 12、14、16mm 三種 , 可演變出六種機型提供0.1~32kg/h 的不同輸出量供客戶選擇。另有雙色色母機 , 可依客戶需求搭配任意兩臺色母機合并使用。
TCM | 系列
The TCM series metering masterbatch mixer is suitable for automatic proportional mixing of new materials, secondary materials, master?batch or additives, etc. This series of models uses a DC brushless motor, which is mixed according to a pre-selected proportion. The conditions set by the touch screen microcomputer control system are automatically converted into rotational speed to directly drive the precision screw extrusion of raw materials, with an error value not exceeding ± 1%. The motor reduction ratio of this product is divided into two types: 30:1 and 100:1, and the screw diameter is divided into three types: 12, 14, and 16mm. It can evolve into six models and provide different output quantities of 0.1-32kg/h for customers to choose from. There is also a dual color master machine, which can be combined with any two color master machines according to customer needs.
使用直流無刷式馬達 , 無需保養 ;
具備數據永久記憶及存儲功能 ;
采用微電腦式控制 , 智能化精確計算 ;
可同時滿足外部信號輸入的要求 ;
螺桿采用鍍鉻處理 , 經久耐用 ;
模組式的裝配結構 , 拆裝方便 , 易于清理及互換 ;
單色色母機機型可選配攪拌器 , 混料均勻 ;
主料斗為雙色色母機的標準配備 , 單色色母機可選配 ;
Brushless DC motor, no maintenance;
With data permanent memory and storage function;
Microcomputer control, intelligent and accurate calculation;
Can meet the requirements of external signal input at the same time;
The screw adopts chrome plating treatment, durable;
Modular assembly structure, easy to disassemble and assemble, easy to clean and interchange;
Single color machine model can be optional agitator, uniform mixing;
The main hopper is standard equipped with two color mother machine, and single color mother machine is optional
|
|
